SOLER800 GasAnalyzers
Stationary automatic multi-channel gas analyzers of the SOLER 800 GasAnalyzer series are designed for automatic continuous monitoring of the concentration of substances in the atmospheric air, in industrial emissions during sampling from gas ducts, boilers, chimneys, etc.
|
Name |
Unit rev. |
Significance |
|
Measured Components |
СО, СО2, SO2, NO, NO2, СН4, О2 |
|
|
Limit of permissible basic reduced error in the measurement range of sulfur dioxide (SO2) from 0 to 2500 ppm, from 0 to 5.0%, % |
Ppm % |
± 5 |
|
Limit of permissible basic reduced error in the measurement range of nitrogen oxide (NO) from 0 to 2500 ppm, from 0 to 5.0%, % |
Ppm % |
± 5 |
|
Limit of permissible basic reduced error in the measurement range of nitrogen dioxide (NO2) from 0 to 500 ppm, % |
Ppm % |
± 5 |
|
Limit of permissible basic reduced error in the measurement range of carbon monoxide (CO) from 0 to 5000 ppm, from 0 to 5.0%, % |
Ppm % |
± 5 |
|
Limit of permissible basic reduced error in the measurement range of carbon dioxide (CO2) from 0 to 10000 ppm, from 0 to 100%, % |
Ppm % |
± 5 |
|
Limit of permissible basic reduced error in the measurement range of methane (CH4) from 0 to 2000 ppm, from 0 to 10%, % |
Ppm % |
± 5 |
|
Limit of permissible basic reduced error in the range of measurement of the volume fraction of oxygen from 0 to 25%, % |
% |
± 5 |
|
Analog output |
мА |
from 4 to 20 |
|
Output digital signal |
RS-232 |
|
|
Time to establish indications, no more |
с |
10 |
|
Gas consumption |
l/min |
from 0.7 to 1.2 |
|
Gas analyzer warm-up time, no more |
min |
30 |
|
Operating temperature range |
°С |
from 5 to 50 |
|
Relative Humidity |
% |
from 5 to 85 |
|
Atmosphere pressure |
kPa |
from 86 to 108 |
|
Sample temperature |
°С |
from 5 to 50 |
|
Sample pressure |
kPa |
from 2 to 50 |
|
AC supply voltage frequency 50 |
Hz, V/Hz |
|
|
Dimensions, |
mm |
480×450×160 |
|
Weight, no more |
kg |
20 |
/ 50±1
Scope - energy, petrochemistry, cement industry, metallurgical enterprises and others.
monitoring industrial elections
The environmental monitoring system, designed for industrial enterprises and environmental laboratories, is designed and manufactured according to the requirements of each Customer
At the same time, we guarantee full compliance with the requirements:
Environmental Code of the Republic of Kazakhstan dated January 2, 2021 № 400-VI
Federal Law № 39-FZ of March 9, 2021 "On Amendments to the Federal Law "On Environmental Protection" of the Russian Federation"
